VAISALA溫濕度傳感器HMD60系列性能參數
Relative Humidity Measurement Performance | |
Humidity Sensor Options | |
HUMICAP R2 | Latest generation industrial sensor with improved corrosion resistance |
HUMICAP 180V | Humidity sensor with a catalytic surface for processes with H2O2 |
Measurement range | 0 ... 100 %RH |
Stability | ±0.5 %RH/year in typical HVAC applications |
Accuracy at 0 … +40 °C (+32 … +104 °F) | |
0 ... 90 %RH | ±1.5 %RH |
90 ... 100 %RH | ±2.5 %RH |
Accuracy at +40 … +80 °C (+104 … +176 °F) and -40 ... 0 °C (-40 ... +32 °F) | |
0 ... 90 %RH | ±2.5 %RH |
90 ... 100 %RH | ±3.5 %RH |
Factory calibration uncertainty | ±1.0 %RH |
Start-up and Response Time | |
Start-up time at +20 °C (+68 °F) | 8 s |
Response time (T63) at +20 °C(+68 °F) | 15 s |
Calculated Humidity Parameters (Default Analog Output Scale) | |
Dew point | -40 ... +80 °C (-40 ... +176 °F) |
Dew point / frost point | -40 ... +80 °C (-40 ... +176 °F) |
Absolute humidity | 0 … 300 g/m3 (0 … 131.1 gr/ft3 ) |
Wet bulb temperature | -40 ... +80 °C (-40 ... +176 °F) |
Enthalpy | -40 … 1600 kJ/kg (-9.5 ... 695.6 Btu/lb) |
Mixing ratio | 0 … 600 g/kg (0 … 4200 gr/lb) |
VAISALA溫濕度傳感器HMD60系列介紹
變送器的全金屬機身非常適合在建筑工地和工業環境中使用。 得益于VAISALA HUMICAP R2 傳感器，HMD60 系列提供了優質的穩定性和環境耐受性。 測量精度高達 ±1.5 %RH 和 ±0.1 °C (±0.18 °F)。所有常見的濕度參數都可用，包括 RH、露點、焓和濕球溫度。
The all-metal body of the transmitter is well suited for use at building sites and industrial settings. HMD60 series provides state-of-the-art stability and environmental resistance thanks to the Vaisala HUMICAP? R2 sensor. The measurement accuracy is up to ±1.5 %RH and ±0.1 °C (±0.18 °F). All common humidity parameters are available, including RH, dew point, enthalpy, and wet bulb temperature.
HMD62 用于測量濕度和溫度
TMD62 僅用于測量溫度
HMD65 用于使用 BACnet 和 Modbus 協議測量濕度和溫度
HMD60 用于使用短探頭測量濕度和溫度，完全可配置
TMD60 僅用于使用短探頭測量溫度，完全可配置
HMD62 for measuring humidity and temperature
TMD62 for measuring temperature only
HMD65 for measuring humidity and temperature with BACnet and Modbus protocols
HMD60 for measuring humidity and temperature with a short probe, fully configurable
TMD60 for measuring temperature only with a short probe, fully configurable
VAISALA溫濕度傳感器HMD60系列其他常用型號：
VAISALA HMD62
VAISALA TMD62
VAISALA HMD65
VAISALA HMD60
VAISALA TMD60
