[Us] rated supply voltage

240 V

network number of phases

Three phase

continuous stall current

2.85 A

continuous power

1.05 W

maximum current Irms

9.6 A for LXM32.D18M2
9.6 A for LXM32.U90M2

maximum permanent current

9.56 A

second shaft

Without second shaft end

shaft diameter

11 mm

shaft length

23 mm

key width

18 mm

feedback type

Multiturn SinCos Hiperface

motor flange size

70 mm

number of motor stacks

1

torque constant

0.49 N.m/A at 120 °C

back emf constant

31.17 V/krpm at 120 °C

number of motor poles

10

rotor inertia

0.59 kg.cm2

stator resistance

3.2 Ohm at 20 °C

stator inductance

9.1 mH at 20 °C

stator electrical time constant

2.8 ms at 20 °C

maximum radial force Fr

660 N at 1000 rpm
520 N at 2000 rpm
460 N at 3000 rpm
410 N at 4000 rpm
380 N at 5000 rpm
360 N at 6000 rpm

maximum axial force Fa

0.2 x Fr

type of cooling

Natural convection

length

122 mm

centring collar diameter

60 mm

centring collar depth

2.5 mm

number of mounting holes

4

mounting holes diameter

5.5 mm

circle diameter of the mounting holes

82 mm

net weight

1.6 kg
